Haswing Armada 10.0 | 6 kW
Input power: 6 kW
Status:
available
Shipping:
3-4 business days (available for immediate delivery)
2.699,00 €
incl. 19% VAT
, excl.
The motor produces audible noise and has an on-board computer and stepless control of the speed.
The Armada 10.0 is available immediately!
control
Product configurator
outboard
1 x Haswing Armada 10.0
available
6 kW
€2,699.00
Selected
Motor
1 x 48V 100Ah LiFePO4
available
5.12 kWh
€1,699.00
Selected
1 x Ultimatron 48 V 150 Ah Bluetooth
available
7,68 kWh
€1,999.00
1 x Ultimatron 48V 100Ah Bluetooth set
available
5,12 kWh
€2,199.00
1 x 48V 200Ah LiFePO4
orderable
10,24 kWh
€3,199.00
1 x Lithimo battery case 6 kWh 48V
available
6 kWh
€3,399.00
Battery
1 x ACES charger 48V/15A 800W
available
800 W
€399.00
Selected
1 x CS-Electronic 48V/15A Charger 880 W
not available
880 W
€230.00
1 x ACES charger 48V/25A 1350W
available
1.350 W
€449.00
1 x ACES charger 48V/35A 2000W
available
2.000 W
€599.00
1 x ACES charger 48V/50A 3300W
available
3.300 W
€999.00
Accessories
BMV-712 Smart with Buetooth and Shunt
available
€223.00
Optional
Battery Monitor BMV-700
available
€154.00
Optional
Charger
Main switch 48V
available
€54.00
Optional
1 x Haswing Armada Propeller
available
plastic
incl.
Selected
Summary
1 x Haswing Armada 10.0
€2,699.00
1 x 48V 100Ah LiFePO4
€1,699.00
1 x ACES charger 48V/15A 800W
€399.00
1 x Haswing Armada Propeller
incl.
Total price
€4,797.00
Properties Haswing Armada 10.0
Input power
6 kW
comparable thrust
10 PS
thrust
300 lbs
Voltage
48 V
noise
75 dB
Noise level
almost silent
rotations per minute
1200 rpm
weight
27.7 kg
display
board computer with digital display
kill switch
Yes
shafttype
short/normal shaft
shaft length
67 cm
control
tiller
Speed control
stepless
saltwater resistant
Yes
cooling
Water
propeller
plastic
tilting mechanism
manual
trimming mechanism
manual 4-stage
tiltable tiller
Yes
telescopic tiller
Yes
maximum boat weight
3000 kg
recommended boat length
10 m
Haswing Armada 10.0 with new update!
We have the first (and only) Haswing Armada 10.0 motors in Europe with the update in stock. The motor no longer delays when switching from forward to reverse, making it much easier to maneuver.
Haswing Armada 10.0 outboard motor
-
The outboard motor from Haswing is suitable for medium-sized motorboats and as a calm water propeller for sailboats.
-
Boat drives from Haswing are fundamentally suitable for use in salt water. After use, the motors should then be thoroughly rinsed with fresh water.
-
When removing the magnetic chip at the end of the safety line, a sensor activates the motor stop. This stops the motor for safety in case of falling overboard. The magnetic switch is located on the tiller or on the remote control.
-
The LED display of the motor shows the current battery voltage.
-
The shaft can be folded up on the holder to avoid ground contact.
Comparison of outboard motors from 6 kW
|
|
|
|
|
|
|
|
|
|
|
|
Haswing Armada 10.0 | ePropulsion Navy 6.0 EVO | Torqeedo Cruise 6.0 R | Mercury Avator 35e | Mitek 9.9 | Elco EP-14 | Elco EP-20 | Aquamot Trend 8.0 | Hy.G 6 kW | |
| Price | 2.699,00 € | 3.499,00 € | 4.599,00 € | 5.179,00 € | 4.799,00 € | 5.799,00 € | 6.379,00 € | 6.839,00 € | 8.899,00 € |
| Availability |
available
|
available
|
available
|
available
|
available
|
available
|
available
|
available
|
available
|
| Shipping | 3-4 business days | 2-3 business days | 3-4 business days | 1-2 weeks | 2-3 weeks | 3-5 business days | 3-5 business days | 3-4 weeks | 3-4 weeks |
| Input power | 6 kW | 6 kW | 6 kW | 4.4 kW | 5.2 kW | 6.2 kW | 8.4 kW | 8 kW | 7 kW |
| comparable thrust | 10 PS | 9.9 PS | 9.9 PS | 8 PS | 9.9 PS | 14 PS | 20 PS | 15 PS | 20 PS |
| Voltage | 48 V | 48 V | 48 V | 48 V | 48 V | 48 V | 48 V | 48 V | 48 V |
| noise | 75 dB | 55 dB | - dB | - dB | - dB | - dB | - dB | - dB | - dB |
| weight | 27.7 kg | 36 kg | 21 kg | 21.3 kg | 28 kg | 38.5 kg | 38.5 kg | 52.2 kg | 19 kg |
Comfort from Haswing Armada 6 kW outboard motor
-
Stepless speed control with the advantage of lower 10% power consumption.
. -
The shaft height of approximately 80 cm allows for use on inflatable boats, small motor boats, and sailboats up to 4500 kg.
-
The Armada 10.0 is available with either a tiller or remote throttle control. The 180° tiltable tiller also serves as the throttle.
-
A practical LED battery indicator with 3 lights always shows you the status of the battery while driving. However, the indicator does not work well with lithium batteries. We recommend a separate shunt measurement.
-
The motor weighs only 27.7 kg, making it a lightweight compared to some competitors or conventional gasoline engines.
-
The pin can be folded up and down, fixed and even extended! As usual with Haswing, everything has been thought of here.
-
LED display does not work well with lithium batteries. Therefore, we recommend lithium batteries with Bluetooth, their own display or a Victron measuring shunt.
-
Noise development possible even with maintenance-free brushless motor.
Technical features of the Haswing Armada 10.0
-
Including a 3-blade plastic propeller.
-
The integrated anti-cavitation plate above the propeller avoids air being sucked in by the propeller. The engine does not have to dive as deep and still provides optimal propulsion.
. -
Integrated water cooling with impeller for motor and control electronics. The water jet exits the cooling system on the underside of the motor head.
-
Infinitely variable adjustment of the propeller's immersion depth in the water. Can be used individually for any height.
-
Newly designed motor housing with the integrated fin is even more flow-optimized.
-
The electric motor can be locked in various positions or tilted out of the water at the touch of a button.
-
A 30 cm cable with SB175 high current battery connector is installed on the Armada 10.0. The included 130 cm extension cable to the battery also has an adequate connector and a robust main switch to disconnect the engine from the power supply.
.
The manufacturer Haswing in comparison
Haswing is a Chinese manufacturer that has developed a wide range of electric stern and bow motors in recent years. Favorable prices and a good price-performance ratio distinguish Haswing.
Despite the good price, the motors are still very solid in quality and can easily keep up with other manufacturers. From therefore our recommendation for a cheap model with good workmanship is clearly with an outboard from Haswing.
.Experience Haswing Armada 10.0
Compared to Haswing, you can find even more manufacturers of electric motors from no-name manufacturers on the Internet, which are produced as OEM products in China. With these electric motors, the quality is poor to assess. Also, customer service is usually poor and spare parts are difficult to obtain.
Haswing, on the other hand, has a global distribution network and also contacts in Germany, which can also supply accessories and spare parts. So you are in any case on the safe side. For price-conscious boaters Haswing is absolutely recommended and also the quality is very reliable.
.How does the order process work?
Simply click on "Add to cart". In the next step, enter your personal data and choose your preferred payment method.
As a specialist dealer, we will check your order and send you an order confirmation and invoice. After receipt of payment, we will send the desired items directly to the desired delivery address.
Within Germany, the delivery time is 3-4 working days. Of course, you will also receive a tracking link for your order.
Afterwards, we are always available personally for questions about assembly. Of course, we also provide instructions, tips and soon also explanatory videos.
For all products in our range, we offer a 2-year warranty - for some products even more.
In case of complaints, we are your contact person, we help you to ensure that everything runs smoothly. You can always reach us by email or phone. We also provide support for possible spare parts at any time. Your boat is our drive.
