Rim Drive Pod 11
Input power: 11 kW
Status:
available
Shipping:
3-4 weeks
11.299,00 €
incl. 19% VAT
, excl.
Product configurator
Pod motor
1 x Rim Drive Pod 11
available
11 kW
€11,299.00
Selected
Motor
2 x Ultimatron 48 V 150 Ah Bluetooth
available
15.36 kWh
€3,998.00
Selected
2 x Batterytechnology 48 V 100 Ah LiFePO4 battery
upon request
4,56 kWh
€5,698.00
2 x Batterytechnology 48 V 200 Ah LiFePO4 battery
available
9,12 kWh
€8,998.00
Battery
1 x ACES charger 48V/25A 1350W
available
1.350 W
€449.00
Selected
1 x ACES charger 48V/15A 800W
upon request
800 W
€399.00
1 x ACES charger 48V/35A 2000W
available
2.000 W
€599.00
1 x ACES charger 48V/50A 3300W
available
3.300 W
€999.00
Accessories
Simarine display
available
€1,199.00
Optional
1 x Rim Drive Pod cable set 8-15 kW
available
€410.00
Selected
1 x Single control lever (side-mounted)
available
€589.00
Selected
1 x Single control lever (top mounting)
available
€589.00
1 x Single control lever (Comfort, top-mounted)
available
€589.00
1 x Rim Drive safety kit pod up to 15 kW
available
€370.00
Selected
Battery Monitor BMV-700
available
€154.00
Optional
Charger
Main switch 48V
available
€54.00
Optional
Summary
1 x Rim Drive Pod 11
€11,299.00
1 x Rim Drive Pod cable set 8-15 kW
€410.00
1 x Single control lever (side-mounted)
€589.00
1 x Rim Drive safety kit pod up to 15 kW
€370.00
2 x Ultimatron 48 V 150 Ah Bluetooth
€3,998.00
1 x ACES charger 48V/25A 1350W
€449.00
Total price
€17,115.00
Properties Rim Drive Pod 11
Input power
11 kW
comparable thrust
20 PS
comparable speed
15 horsepower
thrust
344 lbs
Voltage
48 V
torque
1500 Nm
weight
14 kg
Noise level
almost silent
display
yes
Recuperation
yes
Speed control
stepless
saltwater resistant
yes
cooling
air
propeller
Plastic
maximum boat weight
5500 kg
Security of Rim Drive Pod 11
-
All materials are saltwater resistant, the anode is usually located below the motor.
-
Fishing lines and plants can hardly harm the engines.
-
If a single propeller blade is defective, it can be easily replaced by yourself.
-
A rim drive contains no oils, lubricants or seals.
-
The first motors with Rim Drive technology have been in use since 1929
Comfort of the Pod motor
-
Low weight and narrow dimensions. (also facilitates installation)
-
Stepless speed control ensures efficient operation and easy maneuverability.
-
Essential accessories: throttle, cable set, safety kit
-
Optional accessories: Functional display with integrated communication, shore power kit
-
Also available as a rotatable pod motor (optional)
Comparison of 10 kW hub motors
|
|
|
|
|
|
|
|
|
Rim Drive Pod 11 | Aquamot Trend 11.0 FM | Torqeedo Cruise 12.0 FP | ePropulsion Pod 12 | Mitek 12 Pod | E-Tech 10 POD | |
| Price | 11.299,00 € | 6.599,00 € | 10.049,00 € | 6.999,00 € | 13.799,00 € | 9.869,00 € |
| Availability |
available
|
available
|
available
|
orderable
|
available
|
available
|
| Shipping | 3-4 weeks | 3-4 weeks | 3-4 workdays | 2-3 months | 2-3 weeks | 3-4 weeks |
| Input power | 11 kW | 11 kW | 12 kW | 12 kW | 12 kW | 10 kW |
| comparable thrust | 20 PS | 20 PS | 20 PS | 20 PS | 15 PS | - PS |
| weight | 14 kg | 44.3 kg | 33.5 kg | 35 kg | - kg | - kg |
| Recuperation | yes | no | yes | yes | no | optional |
Technology of the Rim Drive Pod 11
-
A rim drive accelerates from zero to full speed within 1.5 seconds.
-
Very high efficiency, only slightly higher than with normal electric motors with shaft
-
Recuperation possible while sailing or standing still in the water. The batteries recharge while driving at 4 knots or more.
-
No wear parts and 100% maintenance-free. The bearings are water-lubricated and last for thousands of hours under normal use.
-
You can freely choose the direction of rotation of the motors, which optimizes maneuverability, especially in dual motor configurations
-
Rim Drive also offers special underwater motors for very deep waters (used in submarines)
Range of the Rim Drive Pod 11
Travel time and range depend on the battery. In an example with a 4,000 kg boat and a 20 kWh battery, we have the following measurements:
✓ At full load, the battery lasts just under two hours and the boat reaches a speed of 13 km/h. The range was 25 km.
✓ At 1/2 power, the driving pleasure lasts for a 4-hour trip on the water at a marching speed of 10 km/h and a range of 40 km.
✓ Those who plan longer and more leisurely tours on the water can go much further with less power. At 1/5 of the power, a speed of 7 km/h was reached for 10 hours. Overall, a range of 70 km with just one battery charge.
Installation of a pod motor
Due to the current cookie settings, the Youtube video cannot be displayed.
Rim Drive Technology batteries
Rim Drive uses its own LiFePO4 batteries. The motors are perfectly matched to the lithium batteries. The batteries have a relatively good price-performance ratio on the market and a comparatively light weight. Alternatively, the greenboatsolutions batteries from the solar sector are also suitable.
You can see on the individual motors which batteries are suitable due to their performance and capacity. The larger the battery, the better the price per kWh. The 48 V 200 Ah batteries are available for less than 500€ per kWh.
Special feature of external rotor / ring motors
The special feature of the Rim Drive Technology drives is the shape of the ring, so that the drives do not have a classic propeller shaft. The design has the advantage that nothing can get caught in a shaft and if damaged, the propeller blades can be replaced individually. The propeller blades are very sturdy and resistant.
The electric winding is located in the outer housing (stator). The housing itself is cast and does not contain any seals. The inner housing (rotor) with the magnets and propeller blades is also cast, so that no corrosion can occur.
The manufacturer Rim Drive Technology
The Dutch company Rim Drive Technology offers electric boat motors with a power range from 0.5 kW to 50 kW. The existing products are constantly being further developed and new variants are regularly added.
All components are designed and developed in the Netherlands. RDT is committed to the spread of electric drives and compensates for all CO2 emissions. In total, RDT has been developing the motors since 2018.
The prices of the motors are clearly in the premium segment, but especially in the higher power range, there is not much that can beat the manufacturer!
Rim Drive Pod 11 Downloads
Catalogue - Rim Drive Technology
Brochure Power Curves
User manual POD
Reference document - Rim Drive Technology
